Product Details
S908 Hand-Held Vibration Meter - S908 is a compact and reliable hand-held instrument designed for quick measurement of machine vibration levels. It accurately measures displacement, velocity, and acceleration, making it ideal for preventive and predictive maintenance teams.
This lightweight, battery-powered unit is simple to operate and provides instant results for assessing machine health, helping detect common mechanical issues like unbalance, misalignment, and bearing faults. With its user-friendly design and robust performance, the S908 is an excellent choice for maintenance engineers and field technicians.
-
Measures three parameters: displacement, velocity, and acceleration
-
Compact, pen-style design with one-hand operation
-
Easy-to-read 3½-digit LCD display
-
One-button power and measurement control
-
Auto power-off function to conserve battery life
-
Suitable for detecting machine faults such as unbalance, looseness, gear damage, and bearing wear
-
Optional internal or external accelerometer for flexible measurement setups
| Displacement Range | 1–1,999 µm (peak-to-peak) |
| Velocity Range | 0.1–199.9 mm/s RMS |
| Acceleration Range | 0.1–199.9 m/s² Peak |
| Accuracy | ± 5% |
| Frequency Response | Displacement: 10–500 Hz Velocity: 10–1000 Hz Acceleration: up to 10,000 Hz |
| Display | 3½-digit LCD |
| Sampling Rate | 1 reading per second |
| Power Supply | 9 V (6F22) battery |
| Battery Life | Approx. 25 hours of continuous operation |
| Dimensions | 130 × 60 × 22 mm |
| Weight | Approx. 200 g |
| Operating Temperature | 0 °C – 40 °C |
| Form Factor | Hand-held, portable |
| Packaging Type | Box |
-
Routine monitoring of motors, pumps, fans, gearboxes, compressors, and rotating equipment
-
Quick field inspections and go/no-go vibration checks
-
Detection of machine faults such as unbalance, misalignment, and bearing wear
-
Ideal for predictive maintenance, reliability testing, and quality control
